Electrodes for i5 Semi-Automatic Defibrillator with 7” Screen

The DA-PADi5 is an advanced defibrillation pad designed for adult patients weighing over 25 kg . Made with 1 mm thick medical-grade foam, it guarantees maximum adaptability, comfort, and effectiveness during emergency procedures. Each electrode has a total surface area of 148 cm² and an active area of 95 cm², optimizing energy transfer during defibrillation.

Strengths:

- Thermal gradient technology, which reduces the risk of burns and ensures uniform current distribution.

- Low impedance adhesive conductive gel to improve conduction and minimize artifacts.

- Metallic foil as a conductive material, latex-free, ideal for sensitive patients.

- 120cm cable length with safety connector, suitable for a wide variety of medical equipment.

- Withstands up to 50 discharges of 360J, meeting the highest international standards:

Directive 93/42/EEC (Class IIb)

ANSI/AAMI DF-80

IEC/EN 60601-1, 60601-2-4

ISO 10993-1

Technical characteristics:

- Impedance at 10Hz: <200 Ω

- Impedance at long signals: <3 Ω

- Noise: <20 μV

- Offset after defibrillation: <350 mV

- Leakage current @ 7.5 kV: <250 μA

- DC voltage offset: <10 mV
