Powerheart G3 Elite semi-automatic defibrillator: simple and effective, it has RescueCoach technology

Semi-automatic defibrillator Powerheart G3 Elite: the new generation of G3

Introducing the new Powerheart G3 Elite, the latest AED in Cardiac Science's G3 series. The Powerheart G3 Elite defibrillator uses proven Rescue Ready technology to run automatic daily checks to ensure electrode and battery integrity and functionality, so the G3 Elite is ready to rescue 365 days a year. In addition, it is more resistant to dust than water, and has a modern circuit that improves its reliability and sustainability.

It also enables rescuers of any skill level to respond to sudden cardiac arrest emergencies simply and intuitively. RescueCoach™ guides users through the resuscitation process with step-by-step voice and text prompts , and the G3 Elite offers the most advanced features in the industry, such as automatic shock delivery and pre-attached defibrillation pads to provide rescuers the confidence they need.

Strengths:

- Efficacy: Powerheart G3 Elite uses STAR® biphasic technology to deliver an effective shock, a patented technology proven in successful resuscitations around the world. If another shock is required, the Powerheart G3 Elite defibrillator will deliver an increasingly variable amount of energy to deliver a higher dose to the patient.

- Simplicity: it is designed to be easy to use. Patented RescueCoach technology provides clear self-paced voice and text prompts to suit any rescuer's skill level. The next step is indicated after each critical step is completed. In addition, it determines if a shock is needed and automatically applies it to the victim of sudden cardiac arrest.

- Confidence: Every day, the Powerheart G3 Elite AED performs a complex series of proprietary self-tests on the entire device circuitry to verify not only that the medical-grade battery, proprietary non-polarized pads, and critical components are connected, but also that they remain fully operational for the next day. Many other AEDs test as little as once a week. The highly visible Rescue Ready indicator makes it easy to know the status of the Powerheart G3 Elite at a glance. If your Powerheart AED detects an error in a self-test, the indicator turns from green to red and sounds an audible alarm to indicate that the AED needs to be serviced.

Technical characteristics:

• Defibrillator:

- Operations: Fully automatic or semi-automatic version

- Waveform: Biphasic truncated exponential STAR®

- Treatment interval (J): From 95 J to 351 J (adults)

- Voice prompts: RescueCoach™ prompts provide self-paced instructions

- Text display: Displays prompts and critical information for resuscitation

- Audible prompts/alerts: Voice prompts for resuscitation and CPR, system alerts

- Synchronized download: Integrated automatic synchronization function

- Detection and rejection of pacemaker pulses: Yes

- Suitable for pediatric patients: Yes

- Customizable: Voice prompts, CPR settings and shock protocols via MDLink

- CPR: Metronome for compression rate in CPR

- Visible indicators: Rescue Ready® status indicator, battery, patch, operating status

• Physical / environmental characteristics:

- Dimensions (Height × Width × Depth): 8 cm x 27 cm x 31 cm (3.3” x 10.6” x 12.4”)

- Weight: 3.1 kg (6.6 lb), battery and pads included

- Environmental operating conditions: 0°C to 50°C (32°F to +122°F)

• Pads: Intellisense™ Defibrillation Pads:

- Type: Disposable, non-polarized (the patches can be placed in any position). Available in a smaller size for pediatric patients

- Shelf life: 24 months (min.)

• Battery: Intellisense® Lithium Battery

- Period of validity/warranty: Period of validity of 5 years from the date of manufacture / guarantee of complete replacement of 4 years*

- Capacity/performance: 290 discharges at 300 VE (characteristic value), output voltage: 12 V DC (nominal), 16 hours (characteristic value) of operation

• Automatic tests:

- Daily, weekly and monthly: Electrical circuit, AED software, defibrillation patches and medical grade battery

- Weekly: Includes partial load

- Monthly: Includes full charge cycle

• Documentation of the activity:

- Internal memory: 60 minutes of rescue data, multiple rescue function

- ECG and Resuscitation Summary: Viewable through RescueLink reporting and MDLink configuration software

- Communications: Direct connection cable

Warranty:

Cardiac Science Corporation ("Cardiac Science") warrants to the original end-user purchaser that its AED and disposable defibrillation pads will not
shall be free from defects in material and workmanship in accordance with the terms and conditions of this limited warranty (“Limited Warranty”).

Cardiac Science Intellisense® batteries are covered by a "performance guarantee" which is also posted on the website.
Cardiac Science website.

For purposes of this limited warranty, the original purchaser is deemed to be the original end user of the purchased product. This limited warranty is
NON-TRANSFERABLE and INALIENABLE.

If you are viewing a paper copy of this Cardiac Science Limited Warranty, you may find the most current version posted on the site
Cardiac Science website.

During how much time?

This limited warranty covers the following products or replacement parts for the periods of time indicated below:

1. Seven years from the date of original shipment to the original purchaser of the Powerheart AEDs.

2. Disposable defibrillation pads are guaranteed until the expiration date printed on the package.
