iM60 Multiparameter Monitor with 10.4” Touchscreen for Continuous Patient Monitoring in Demanding Clinical Environments

The iM60 is an advanced multiparameter monitor designed for continuous patient monitoring in demanding clinical environments such as ICUs, operating rooms, and emergency departments. It features a high-resolution TFT touchscreen , providing a clear and intuitive display of multiple vital parameters. It stands out for its high clinical performance , integration with central monitoring systems, and expanded physiological analysis capabilities.

Strengths

- Large format touch screen (10.4”) , which improves interaction and clinical visualization.
- High multiparameter monitoring capacity , suitable for adult, pediatric and neonatal patients.
- Advanced arrhythmia and ST segment analysis .
- Modular and expandable system , with multiple optional features according to clinical needs.
- Advanced connectivity , compatible with hospital monitoring centers.
- Robust and reliable design , suitable for critical environments.
- Extensive data storage and review options .
- Intuitive interface , optimized to facilitate the work of healthcare personnel.

Technical Specification

- Type of equipment : multiparameter patient monitor.
- Screen : 10.4-inch color TFT, touchscreen.
- Standard parameters :
ECG (3/5 leads)
SpO2
NIBP (non-invasive blood pressure)
Breathing
Temperature (2 channels)
Pulse rate
- Clinical functions :
Arrhythmia analysis
ST Segment Analysis
Pacemaker detection
Protection against defibrillation
- Display capability : multiple simultaneous curves (depending on configuration).
- Storage : internal memory with the possibility of data export.
- Connectivity :
Network for integration with central monitoring station
USB ports
Video outputs (depending on configuration)
- Optional :
CO₂ Module
Invasive pressure (IP)
Advanced SpO2 (Nellcor or others)
Integrated thermal printer
Wireless connectivity (WLAN)
- Power supply : integrated rechargeable battery + mains electricity connection.
