iM70 12.1” Touchscreen Multiparameter Monitor for Advanced Patient Monitoring in Critical Environments

The iM70 is a high-performance multiparameter monitor designed for advanced patient monitoring in critical care environments such as ICUs, operating rooms, and specialized care units . It features a 12.1-inch TFT touchscreen , providing a wide, clear, and configurable display of multiple physiological parameters. It is designed to offer maximum accuracy, connectivity, and clinical analysis capabilities , adapting to different patient profiles (adult, pediatric, and neonatal).

Strengths

- Large touchscreen (12.1”) , which improves the simultaneous display of data and curves.
- Advanced multiparameter monitoring , suitable for critical environments.
- High level of customization and configuration , according to clinical needs.
- Advanced arrhythmia and ST segment analysis.
- Extensive modular expansion capacity , with multiple optional parameters.
- Integration with hospital monitoring centers .
- Intuitive and easy-to-use interface , optimizing clinical operations.
- Robust and reliable design , prepared for intensive continuous use.

Technical Specification

- Type of equipment : high-end multiparameter patient monitor.
- Screen : 12.1-inch color TFT, touchscreen.
- Standard parameters :
ECG (3/5 leads)
SpO2
NIBP (non-invasive blood pressure)
Breathing
Temperature (2 channels)
Pulse rate
- Clinical functions :
Arrhythmia analysis
ST Segment Analysis
Pacemaker detection
Protection against defibrillation
- Display capability : multiple simultaneous curves (configurable).
- Storage : internal memory with storage of trends and events.
- Connectivity :
Integration with central monitoring station
USB ports
Video outputs (depending on configuration)
Wired and wireless network options
- Optional :
CO₂ (capnography)
Invasive pressure (IP)
Advanced SpO2 (Nellcor or other technologies)
Integrated thermal printer
WLAN module
Additional screen or mounting accessories
- Power supply : integrated rechargeable battery + mains electricity connection.
